StarTech.com Multi-Input HDBaseT Extender Kit with Built-In Switch and Video Scaler – DisplayPort HDMI and VGA Over CAT6 or CAT5e

Manufacturer:StarTech.com
Manufacturer Part Number:ST121HDBTSC
Manufacturer Website Address:http://www.startech.com
Brand Name:StarTech.com
Product Name:Multi-Input HDBaseT Extender Kit with Built-In Switch and Video Scaler
Marketing Information:

This multi-input HDBaseT™ extender kit extends your A/V signals to a remote location up to 230 ft. (70 m) away. It features a built-in switch and scaler, so you can choose which video source is output from four independent video sources (2 x HDMI, 1 x VGA and 1 x DisplayPort).

Seamless Integration and Operation

TheHDBaseT extender’s built-in converter switch lets you connect two HDMI sources, a VGA source, and a DPsource to the same remote and local HDMI display. You don’t needadapters or scalers, or a video switch.

Along with manuallyswitching your video source with easy-to-use buttons, the video extender ensures hassle-free operationwith twoauto-switching modes: auto-detect switching, which detects and selects a newly connected device, andpriority selection, which lets you choose whichport is activated by default, for automatic switching.

Built-In Video Scaling

This HDBaseT extenderfeatures a built-in scaler that scales the image to 1080p, so you can rest assured yourHDMI display will intuitively work with any source that’s connected through it. Scaling is easy to do,with an intuitive OSD that’s accessible using buttons on theremote receiver. Newer HDMI displays no longer support legacy resolution video signals. Without support for these common VGA resolutions, your source may not work with your new HDMI display.

High-Definition 1080p Video at230 Feet (70 Meters)

The extender kit maintains your HD picture quality, even at230ft. (70 m) away from your video source, ensuringyou can provide the best possible viewing experience.

The ST121HDBTSC is backed by a 2-year StarTech.com warranty and free lifetime technical support.

Packaged Quantity Condition:Kit
Product Type:Video Extender Transmitter/Receiver

Connectivity Technology:Wired
Number of Input Devices Supported:4
Number of Output Devices Supported:1
Maximum Operating Distance:229.66 ft

Graphics Modes:WUXGA
Maximum Video Resolution:1920 x 1200

Network (RJ-45):Yes
HDMI In:Yes
HDMI Out:Yes
VGA In:Yes
DisplayPort:Yes
Number of Network (RJ-45) Ports:2
Number of HDMI Inputs:2
Number of HDMI Outputs:2
Number of VGA Inputs:1

Media Type Supported:Twisted Pair
Twisted Pair Cable Standard:Category 6

Product Color:Black
Transmitter Height:2.60″
Transmitter Width:2.40″
Transmitter Depth:4.20″
Receiver Height:2.60″
Receiver Width:2.40″
Receiver Depth:4.20″
Form Factor:Desktop
Transmitter Weight (Approximate):4.41 lb
Receiver Weight (Approximate):4.41 lb

Package Contents:

• 1 x HDBaseT Transmitter
• 1 x HDBaseT Scaler Receiver
• 1 x Remote Control
• 1 x RJ-11 to RS-232 Adapter
• 1 x CAT5 Cable
• 1 x RJ-11 Cable
• 2 x Sets of Mounting Brackets
• 1 x Universal Power Adapter (NA/JP, EU, UK, ANZ)
• 1 x IR Blaster
• 1 x IR Receiver
• 2 x Sets of Rubber Feet
• 1 x Quick-Start Guide

Environmentally Friendly:Yes
Country of Origin:Taiwan
TAA Compliant:Yes

Limited Warranty:2 Year
