StarTech.com 1 Port Gigabit PoE+ Extender – 802.3at and 802.3af – 100 m (330 ft) – Power over Ethernet Extender – PoE Repeater Network Extender

Manufacturer:StarTech.com
Manufacturer Part Number:POEEXT1GAT
Manufacturer Website Address:http://www.startech.com
Brand Name:StarTech.com
Product Name:1-Port Gigabit PoE+ Extender – 802.3at and 802.3af – 100 m (330 ft)
Marketing Information:This Gigabit PoE+ extender spans your Power over Ethernet (PoE) device over longer distances, letting you double the 100m limitations of a traditional PoE infrastructure.

Now you can connect your Gigabit PoE device up to a maximum of 200m away, so it’s easy to install a remote IP camera or access point. Plus the extender can be daisy-chained for more scalability.

Unrestricted PoE+ range and convenience

Need more distance? This convenient PoE+ repeater maximizes range and flexibility by extending your PoE connection by an extra 100m (330ft), while providing 24-watt power output to compatible devices.

Simply connect the extender to your power sourcing equipment (PSE) and your PoE-powered device (PD) and you’re all set. The extender is compliant with the 802.3at/af standard, so it will work with existing PSE, such as a StarTech.com PoE+ switch (IES81000POE).

Daisy chain for longer distance and flexibility

Still need more distance? If an extra 100m isn’t enough, this full-featured PoE extender offers daisy chain capability.

You can easily connect four extenders together, letting you install your PoE+ PD up to 500m (1640ft) away. It’s perfect for business, education, and retail environments (output wattage is dependent on the number of daisy-chained extenders used).

Convenient installation options and durable construction

Get up and running quickly. This Gigabit PoE+ extender can be positioned right where you need it, with a wall-mountable design that requires no external power adapter.

You can enjoy reliable performance with little worry of downtime or failure, the extender features a rugged metal housing with built-in ESD and surge protection.

The POEEXT1GAT is backed by a StarTech.com 2-year warranty and free lifetime technical support.

Applications

• Ideal for Wi-Fi® access points, IP phones, surveillance cameras, and kiosks where a power connection is not available
• Enable remote installation of PoE+ devices over longer distance than conventional PoE range capabilities
• Perfect for SOHO, SMB, system integrators, and IT administrators

Packaged Quantity:1
Product Type:PoE Extender

Protection Type:

• Surge Protection
• ESD Protection

Minimum Output Voltage:52 V DC
Maximum Output Voltage:56 V DC
Maximum Output Power:24 W

Input Ports:1 x Gigabit Ethernet
Output Ports:1 x Gigabit PoE+

Product Color:Black
Form Factor:Wall Mountable
Height:1″
Width:2.7″
Length:3.7″
Weight (Approximate):6.81 oz

Package Contents:

• 1-Port Gigabit PoE+ Extender – 802.3at and 802.3af – 100 m (330 ft)
• 1 x Instruction Manual

Additional Information:

• Color: Black
• Enclosure Type: Steel
• Input Voltage: 52 ~ 56 DC
• Power Consumption: 3.2 W Max
• Connector Type(s): 2 – RJ-45 Female
• MTBF: 50,000 Hours
• Compatible Networks: 10/100/1000 Mbps
• Flow Control: Half-duplex back-pressure, IEEE 802.3x pause frame for full-duplex
• Maximum Cable Length: 328 ft [100 m]

Compatibility:Compatible Products:

• Wi-Fi Access Points
• IP Phones
• Surveillance Cameras
• Kiosks

Certifications & Standards:

• IEEE 802.3af
• IEEE 802.3at
• IEEE 802.3
• IEEE 802.3u
• IEEE 802.3ab

Environmentally Friendly:Yes
TAA Compliant:Yes

Limited Warranty:2 Year
